PLF-Q Series Automatic Slag Discharge Scraper Centrifugal Oil Purifier
USES:
Automatic slag discharge centrifugal net oil machine is mainly used in the design and use of coolant, cutting fluid, grinding fluid, drawing fluid, rolling fluid and other metal processing and manufacturing industries, such as metal parts processing, automobile engine manufacturing, automobile transmission manufacturing enterprises.
Screw and nut forming machine oil, head machine rubbing machine oil, heat treatment oil, discharge processing machine oil, punch oil, calender oil, other various industrial circulation oil, large gear box oil, cable processing oil, grinding processing oil, bearing fine grinding oil, electric spark processing oil, screw processing oil; Hard disk processing sewage, glass processing sewage, ceramic processing sewage, vibration grinding sewage, automobile coating sewage, cutting tool processing sewage, silicon crystal grinding sewage, water liquid, etc.
Applicable oil:
Copper wire drawing oil, aluminum wire drawing oil, screw forming oil, spark oil, stainless steel drawing oil, quenching oil, screw and nut forming oil, hydraulic machinery oil, heavy load gear oil, high viscosity oil, turbine oil, lubricating oil, crude oil, etc.
Principle:
The use of high-speed solid-liquid separation centrifuge, so that the impurities into the drum, due to its different proportion, in the high-speed rotation of the drum, the centrifugal force generated tens of thousands of times larger than the gravity of natural sedimentation, separation and precipitation process continuously and quickly. The huge centrifugal force in the drum can achieve the separation effect in a few seconds that can be achieved by the natural gravity action of several hours in the precipitation tank. Solid particles are quickly separated, and the dried particles are discharged automatically through the automatic unloading mechanism.
Features:
● Oil or water liquid after separation, the original characteristics unchanged, prolong the service life.
● The separator slag removal efficiency of 95%, automatic discharge of solid particles dry.
● Reduce oil or water liquid consumption, reduce waste liquid treatment, reduce filter material consumption: > 90%.
●Reduce machining tool loss, reduce defective rate and reject rate.
●Improve machine operation time, reduce machine maintenance time, and steadily improve machining quality.
●Improve working environment: eliminate oil mist,PLC automatic control.
Technical Parameter List
Model | LS-PLF-Q50 | LS-PLF-Q80 | IS-LF-Q120 |
Application | Oil or Aqueous | ||
Flow Rate | 50L/min | 80L/min | 120L/min |
Total Power | 8Kw | ||
Available Temperature Range | 0-120℃ | ||
Available Viscosity Range | ≤320cts. | ||
Weight | 720KG | ||
Air Source | 0.5-0.7MPa | ||
Oil Inlet | 25-32mm | ||
Oil Outlet | 90-110mm | ||
Size of Slag Carrier(L*W*H) | 1000mm×710mm×720mm | ||
Size of Centrifuge(L*W*H) | 1100mm×850mm×1420mm | ||
Stander Size(L*W*H) | 1300mm×1030mm×930mm | ||
