Technical Parameter
Working condition |
|
Power | AC220Vt10% Frequency Unlimited |
AC high voltage output | 400V~2200V±2%interval 100V 50VA |
| 200V - 600V t2% interval 50V |
Temperature control induction furnace | 50VA; output current : 25mA |
Temperature control range | <100℃ |
Temperature control error | ±0.5℃ |
Temperature measurement resolution | 1℃ |
Temperature control time | Room temperature to 90℃, less than 20min |
Measuring range | Tgo Unlimited |
Cx 15PF-300PF | |
Rx 10M-20T | |
Resolution | △Tgo 0.001% |
△Cx 0.01pF | |
△Rx 0.01 | |
Accuracy | △Tgo ±(reading×0.5%+0.020%) |
△Cx ±(reading×0.5%+0.5PF) | |
△Rx ±reading×10% | |
Relative dielectric constant | Εr automatic calculation according to Cx |
Volume resistivity | Ρ automatic calculation according to Rx |
Dimension | 450×310×360mm³ |
Weight | 18Kg |
Distance between HV and LV | 2mm |
Capacitance of hollow cup | 60±2PF |
The maximum measurement voltage | Power frequency 2000V |
Dielectric loss of hollow cup | Tgo<1×10-4 |
Liquid capacity | About 40ml |
Electrode material | Stainless steel |
Dimension | 70mm(D)×120mm(H) |
