LS-JF-50;LS-JF-100,LS-JF-200
LUSHUN
LS-JF-50;LS-JF-100,LS-JF-200
DGJ Series Belt-type Oil Scraper
Product Introduction:
DGJ series belt-type oil scraper (also called oil skimmer, oil-water separator, skimmer, oil bailing machine) is the most reliable and economical equipment for oil slicks removal at present. It is easy to operate, low consumption, able to remove various liquid suspending oil slicks (such as machine oil, kerosene, gasoline, diesel, lubricating oil, plant oil, and other greases with specific gravity less than water.) effectively without any other consumables. It can purify and cleanse the oil slicks regardless of layer thickness. Manual operation or automatic operation can be option. It can be timed to operate at different time periods within 24 hours and run with no speed regulation.
Application:
● To remove oil slicks in the water reservoir of various metalworking fluids, rolling emulsion waste water, cleaning fluids.
● For the oil slick collecting pretreatment system of preconditioning regulating reservoir containing oily sewage, oil trap before advanced purification, air floatation separation reservoir.
Technical Specifications:
Item | Model | ||
JF-200 | JF-100 | JF-50 | |
Spec.Of Steel Belt（Width×Thickness） | 200×0.3 | 100×0.2 | 50×0.2 |
Material Of Scraper Belt | Special stainless steel | Special stainless steel | Special stainless steel |
Total Electrical Consumption | 45W | 45W | 30W |
Motor Power | 40W/50Hz | 40W/50Hz | 25W/50Hz |
Weight | 55 | 40 | 25 |
Power Supply | 220V/50Hz single phase | ||
DGJ Series Belt-type Oil Scraper
Product Introduction:
DGJ series belt-type oil scraper (also called oil skimmer, oil-water separator, skimmer, oil bailing machine) is the most reliable and economical equipment for oil slicks removal at present. It is easy to operate, low consumption, able to remove various liquid suspending oil slicks (such as machine oil, kerosene, gasoline, diesel, lubricating oil, plant oil, and other greases with specific gravity less than water.) effectively without any other consumables. It can purify and cleanse the oil slicks regardless of layer thickness. Manual operation or automatic operation can be option. It can be timed to operate at different time periods within 24 hours and run with no speed regulation.
Application:
● To remove oil slicks in the water reservoir of various metalworking fluids, rolling emulsion waste water, cleaning fluids.
● For the oil slick collecting pretreatment system of preconditioning regulating reservoir containing oily sewage, oil trap before advanced purification, air floatation separation reservoir.
Technical Specifications:
Item | Model | ||
JF-200 | JF-100 | JF-50 | |
Spec.Of Steel Belt（Width×Thickness） | 200×0.3 | 100×0.2 | 50×0.2 |
Material Of Scraper Belt | Special stainless steel | Special stainless steel | Special stainless steel |
Total Electrical Consumption | 45W | 45W | 30W |
Motor Power | 40W/50Hz | 40W/50Hz | 25W/50Hz |
Weight | 55 | 40 | 25 |
Power Supply | 220V/50Hz single phase | ||
